PLANET tuoteuutinen: LRP-822CS

8-porttinen PoE over Coax kytkin turvakameraverkkoihin

Julkaistu: 02.08.2015

Centralized Power Management
PLANET LRP-822CS, a brand-new Multi-channel Long Reach PoE Switch, features an extended PoE networking of up to 1000 meters (3,280ft) over the existing coaxial cables going to multiple PoE IP cameras. It provides IPv6/IPv4 dual stack management and built-in L2/L4 Gigabit Switching engine along with 8 BNC ports for connection to Long Reach PoE Extenders, 2 Gigabit copper ports and another 2 100/1000BASE-X SFP fiber slots. With the centrally-managed 240-watt PoE budget, the LRP-822CS eliminates the need for an additional power outlet. It provides a quick, safe and cost-effective PoE network solution to upgrading the existing coaxial cable infrastructure from the analog system to the HD IP surveillance system.

Daisy-chaining Multiple Nodes
Furthermore, the LRP-822CS gives users the flexibility to expand small area network with BNC T-connector for sharing four nodes per port when needed, making the 8 BNC Long Reach PoE Ports an ideal support for up to 32 IP cameras.

8-port BNC Long Reach PoE with Data and Power transmitted over up to 1000m coax cable
240-watt PoE budget centrally and remotely controlled
Up to 25-watt power output to remote 802.3af/at complied PD
PD Alive Check / Scheduled Power Recycling / Time-based PoE Schedule
IGMP Snooping v2 and v3 / MLD Snooping
IPv6 Web interface / SNMP v1, v2c and v3 / SSH / SSL Management
