PLANET tuoteuutinen: GS-5220-46S2C4X

48-porttinen SFP-kytkin 10G-uplink porteilla

Julkaistu: 09.04.2015

PLANET GS-5220-46S2C4X is a Layer 2+ Managed Gigabit Switch that features 46-port 100/1000BASE-X + 2-Port Gigabit TP/SFP + 4-port 10G SFP+ in a 1U case. With 10Gbps uplink, the GS-5220-46S2C4X can handle extremely large amounts of data in a secure topology linking to an enterprise backbone or high capacity servers. As each of the SFP+ slots supports Dual-Speed, 10GBASE-SR/LR or 1000BASE-SX/LX, it is the ideal Big Data solution for data centers, enterprises and SMBs to build redundant connection and establish high bandwidth for server farm.

High-level IPTV Application with MVR (Multicast VLAN Registration)
It's important to reduce the redundant bandwidth of IPTV stream in the higher bandwidth required network. MVR provides the ability to continuously send multicast streams in the multicast VLAN, but to isolate the streams from the subscriber VLANs for bandwidth and security reasons. The GS-5220-46S2C2X offers up to 176Gbps bandwidth to exchange data, voice and video packets. It's a suitable aggregation switch for ISP and Telco in the heavy traffic backbone network.

IPv4 / IPv6 Static Routing
Intelligent SFP digital diagnostic monitor (DDM)
IEEE 802.1Q VLAN / Private VLAN / Q-in-Q
IGMP Snooping v2 and v3 / MLD Snooping / MVR
IEEE 802.1s MSTP and Loop Protection
IPv6 Web interface / SNMP v1, v2c and v3 / SSH / SSL Management
